200 Ton Verson Used Press • 200 Ton Straight Side Double Crank Press

200

200
Ton
60″
Bed R-L
6″
Stroke

Verson S2-200-60-48T 6″ Str., 33″ Sh.Ht., 60″ x 48″ Bed, 40-80 SPM, 35″ Windows, Floor Standing, With Cushions

Machine #3299
(Columbia, TN Warehouse)

Machine Specifications

Used 200 Ton Press for Sale • Straight Side Double Crank Press

Model S2-200-60-48T (1973)
Serial 23785
Condition: Very Good
Contact: Columbia, TN Warehouse #3299

200 TON
STROKE 6″
MAX. SHUT HEIGHT TO BED 33″ SDAU
BED AREA 60″ RL X 48″ FB
SPEED 40-80 SPM
RAM AREA 60″ RL X 48″ FB T-SLOTTED
RAM ADJUSTMENT 8″
BOLSTER SIZE 6″ X 60″ RL X 48″ FB T-SLOTTED
FLOOR TO BED 35″
WINDOWS 35″ WIDE
CLUTCH VERSON AIR CLUTCH AND BRAKE
ELECTRICS 50 HP MOTOR AND CONTROLS
APPROX. DIMENSIONS 18′ HIGH, 11′ RL, 9’4″ FB
APPROX. WEIGHT 72,000 LBS.
Equipped With AIR CUSHIONS floor standing base TIE ROD STEEL FRAME CONSTRUCTION
Note
Location This used Straight Side Double Crank Press is located in our Columbia, TN Warehouse
