Machine Specifications
C Frame Press for Sale
Manufacturer: Stamtec
Model: Stamtec OCP-45 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: 2014
Machine #: 8002
Buy Now: $
| CAPACITY | 50 US TON | STROKE | 3.2″ | MAX DIE HEIGHT | 9.9″ sdau over 3.5″ h bolster | BED AREA | 33.5″ x 14.2″ (rl x fb) | SPEED | 65 – 130 spm | SLIDE ADJUSTMENT | 2.4″ (motorized) | SLIDE AREA | 16.9″ rl x 13.8″ fb (t-slot) | BOLSTER PLATE | 3.5″ h x 33.5″ rl x 17.3″ fb (t-slot) | DISTANCE BETWEEN UPRIGHTS | 19.8″ | DISTANCE FLOOR TO BED | 28″ | CLUTCH | stamtec HIGH PERFORMANCE WET CLUTCH / BRAKE | ELECTRICS | 5 hp 1750 rpm 240/480v-3-60 MOTOR w/teco a510 480v vfd, resistor bank, & LINK 5100 PRESS CONTROL | APPROX DIMENSIONS | 100″ h x 48″ rl x 60″ fb | APPROX WEIGHT | 7,300 LBS | Equipped With | HYDRAULIC OVERLOAD PROTECTION, LOW DEFLECTION, SUPER RIGID STEEL FRAME, EXTRA LONG 6 PT CENTERED GIBS, REMOVABLE BOLSTER & SLIDE PLATE, AUTOMATIC LUBRICATION SYSTEM, SINGLE BACK GEARED DESIGN, FLOOR STANDING | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
