Machine Specifications
C Frame Press for Sale
Manufacturer: Minster
Model: Minster 70-4 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: 1977
Machine #: 6925
Buy Now: $
| CAPACITY | 60 TONS | STROKE | 6″ | MAX SHUT HEIGHT TO BED | 14.25″ SDAU | BED AREA | 32″ X 21″ (rl x FB) | SPEED | 50 SPM | SLIDE ADJUSTMENT | 3″ MANUAL | SLIDE AREA | 21″ RL X 14″ FB | BOLSTER PLATE | APPROX 2.5″ H X 32″ RL X 21″ FB | DISTANCE BETWEEN UPRIGHTS | 15″ | DISTANCE FLOOR TO BED | APPROX 33″ | CLUTCH | MINSTER AIR CLUTCH / BRAKE COMBINATION | ELECTRICS | APPROX 5 HP 1150 RPM 480V-3-60 MOTOR & MINSTER RELAY PRESS CONTROL | APPROX DIMENSIONS | 115″ H X 60″ RL X 72″ FB | APPROX WEIGHT | 14,000 lbs | Equipped With | AIR COUNTERBALANCES, FLOOR STANDING, CAST IRON FRAME | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
