Machine Specifications
OBI Press for Sale
Manufacturer: Minster
Model: Minster B1-60 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: Year Unknown
Machine #: 6000
Buy Now: $
| CAPACITY | 60 TON | STROKE | 2″ | max. shut height to bed | 13.5″ sdau | Slide adjustment | 3″ manual | BED AREA | 32″ X 21″ (rl x fb) | slide area | 16″ rl X 13″ fb | BOLSTER SIZE | 2.5″ h x 30″ rl X 6″ fb & 2.5″ h x 30″ rl X 5″ fb | SPEED | 150 – 250 spm | THROAT DEPTH | 9″ | DISTANCE BETWEEN UPRIGHTS | 15″ | FLOOR TO BED | 32.25″ | CLUTCH | MINSTER AIR CLUTCH / BRAKE COMBINATION | ELECTRICs | APPROX. 10 HP 220/440V-3-60 MOTOR & existing minster relay press control. we can add a new cieco 1100r4 press control for extra $5,000. | APPROX. DIMENSIONS | press – 105″ h x 70″ rl x 74″ fb | APPROX. WEIGHT | 10,000 LBS. | Equipped With | floor standing, cast iron frame | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
