Description
4-Post Used Hydraulic Press • Used 100 Ton Press for Sale
- Machine #
- 4784
- Condition
- Very Good
- Location
- Jackson, MI Falahee Building
- Year
- Year Unknown
- Model
- Adamson United 4-Column
Buy Now: $
| capacity | 100 Ton - down / 30 ton - return |
|---|---|
| max. stroke | 30" |
| max. daylight to bed | approx. 43" |
| overall bed size | 77" x 62" (RL X FB) |
| distance between posts | 57" x 51" (RL X FB) |
| usable bed area | 57" x 62" (RL X fb) OR 51" X 77" (RL X FB) |
| speeds | 253 ipm down, 18 ipm pressing, 276 ipm return |
| CYLINDER SIZES | (2) CYLINDERS APPROX. 7" DIA. BORE |
| ROD SIZES | (2) CYLINDER 4.75" DIA. |
| 4 POST SIZE | 6" DIA. |
| FLOOR TO BED | 13.5" - RISERS CAN BE ADDED |
| PRESS CONTROLS | CUTLER-HAMMER RELAY LOGIC CONTROLLER |
| HYDRAULICS | VICKERS PISTON PUMP PVB10LSY31C11 |
| ELECTRICAL | 20 HP 460V-3-60 MOTOR - 25.3 AMPS |
| OVERALL DIMENSIONS | 98" X 108" (RL X FB) X APPROX 11' TALL |
| APPROX. WEIGHT | 48,000 LBS. |
| Equipped With | __ |
| Note | __ |
| Location | This Used Press is Located in Our Jackson, MI Falahee Building |
