Back Geared OBI Presses

Sustained Power for Heavy Operations: Unlike standard direct-drive machines, back geared Open Back Inclinable (OBI) presses utilize a gear reduction system to deliver massive, sustained kinetic energy throughout a longer portion of the stroke. This mechanical multiplier makes them the definitive choice for deep drawing, heavy forming, and the extrusion of thick materials where a standard flywheel might stall. Our inventory of geared C-frame and gap frame presses provides the rugged, vibration-dampening durability required for rigorous industrial environments, combined with the versatility of an inclinable frame to utilize gravity for efficient part and scrap ejection.

Popular Filtered Searches:


Filter by Tonnage / Size

Stroke (in Inches)

Bed Area (Inches Right to Left)

Weight Capacity (lbs.)

Width (in Inches)

Thickness / O.D. (in Inches)

The Mechanics and Applications of Back Geared OBI Presses

How Gear Reduction Enhances Stamping Force

In a back geared stamping press, the electric motor drives a flywheel that is connected to a pinion gear. This pinion engages a larger bull gear attached directly to the crankshaft. This gear reduction ratio inherently slows the strokes per minute (SPM) but exponentially multiplies the torque applied to the ram. For manufacturing operations that require sustained tonnage starting higher up from the bottom dead center (BDC) of the stroke, a back geared OBI press ensures the tooling punches through thick materials without compromising the motor or structural frame.

Selecting Between Flywheel and Single Geared Presses

Matching the kinetic energy profile of the press to your specific die is critical for part quality and tool longevity:

  • Non-Geared (Flywheel) Drives: Deliver rapid energy release at high speeds, ideal for thin metals, light blanking, and shallow piercing.
  • Single Geared Drives: Provide a steady, sustained release of energy at a lower SPM. This is the industry standard for moderate drawing, heavy-gauge forming, and complex progressive die work where the material requires time to flow.

Integration and Automation Insights: When sourcing used back geared presses, facilities frequently integrate them with modern servo roll feeders, straighteners, and heavy-duty coil reels. Because geared gap frame presses operate at a lower speed than their flywheel counterparts, they offer a wider timing window. This allows automated coil feeding systems ample time to accurately index heavy, rigid materials before the ram descends.

Maximizing ROI with Legacy Geared Press Frames

The heavy cast iron and thick steel weldments utilized in legacy back geared gap frame presses are highly sought after for their superior vibration dampening and structural rigidity. By acquiring a mechanically sound used geared press, manufacturers secure a heavily seasoned frame capable of absorbing massive shock loads without deflection. Facilities routinely pair these rugged frames with modern pneumatic clutch and brake assemblies, OSHA-compliant light curtains, and updated PLC tonnage monitors, successfully achieving new-machine reliability at a fraction of the capital expenditure.
