Description
C Frame Press • Used 50 Ton Press for Sale
Model: Stamtec OCP-45 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: 2014
Machine #: 8003
Buy Now: $
| CAPACITY | 50 US TON | STROKE | 3.2" | MAX DIE HEIGHT | 9.9" sdau over 3.5" h bolster | BED AREA | 33.5" x 14.2" (rl x fb) | SPEED | 65 - 130 spm | SLIDE ADJUSTMENT | 2.4" - motorized (MOTOR MISSING - REPLACEMENT INCLUDED WITH RECONDITIONING) | SLIDE AREA | 16.9" rl x 13.8" fb (t-slot) | BOLSTER PLATE | 3.5" h x 33.5" rl x 14.2" fb (t-slot) | DISTANCE BETWEEN UPRIGHTS | 19.8" | DISTANCE FLOOR TO BED | 28" | CLUTCH | stamtec HIGH PERFORMANCE WET CLUTCH / BRAKE | ELECTRICS | 5 hp 1750 rpm 240/480v-3-60 MOTOR w/teco a510 480v vfd, resistor bank, & LINK 5100 PRESS CONTROL | APPROX DIMENSIONS | 100" h x 48" rl x 60" fb | APPROX WEIGHT | 7,500 lbs | Equipped With | HYDRAULIC OVERLOAD PROTECTION, LOW DEFLECTION, SUPER RIGID STEEL FRAME, EXTRA LONG 6 PT CENTERED GIBS, REMOVABLE BOLSTER & SLIDE PLATE, AUTOMATIC LUBRICATION SYSTEM, DUAL AIR COUNTERBALANCES, SINGLE BACK GEARED DESIGN, FLOOR STANDING | Note | motorized SLIDE ADJUSTMENT MOTOR CURRENTLY MISSING, TO BE REPLACED WITH RECONDITIONING |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
