Description
C Frame Press • Used 88 Ton Press for Sale
Model: Stamtec G1-80 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: 2001
Machine #: 8275
Buy Now: $
| capacity | 88 us ton | stroke | 2.8" | max die height | 14.6" SDAU OVER 4" H BOLSTER | bed area | 39.4" X 21.7" (RL X FB) | speed | 50 - 120 SPM | slide adjustment | 3.2" MOTORIZED | slide area | 22.1" X 16.6" (RL X FB) T-SLOTTED | bolster plate | 39.4" x 21.7" (RL X FB) 4" THICK t-slotted | distance between uprights | 21" | distance floor to bed | 29" | shank hole size | 1.97" diameter | clutch | STAMTEC AIR CLUTCH / BRAKE COMBINATION | electrics | 10 HP 1750 RPM 240/480V-3-60 EDDY CURRENT DRIVE & STAMTEC PRESS CONTROL | approx dimensions | 60" X 75" (RL X FB) X 125" HIGH INCLUDING MOTOR | approx weight | 15,500 lbs | Equipped With | HYDRAULIC OVERLOAD PROTECTION, LOW DEFLECTION, SUPER RIGID STEEL FRAME, EXTRA LONG 6 PT CENTERED GIBS, REMOVABLE BOLSTER & SLIDE PLATE, AUTOMATIC LUBRICATION SYSTEM, DUAL AIR COUNTERBALANCES, SINGLE BACK GEARED DESIGN, FLOOR STANDING | Note |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
