Description
Straight Side Press • Used 300 Ton Press for Sale
Model: Niagara PN-300-120-30 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: 1992
Machine #: 8020
Buy Now: $
| CAPACITY: | 300 TON | STROKE | 6" | SHUT HEIGHT TO BED | 26" (SDAU) | BED AREA | 120" X 30" (RL X FB) | SPEED | 25 - 50 SPM (VARIABLE) | SLIDE ADJUSTMENT | 6" motorized | SLIDE AREA | 120" X 30" (RL X FB) (T-SLOTTED) | BOLSTER PLATE | 6" H X 120" RL X 68" FB (T-SLOTTED) | DISTANCE BETWEEN UPRIGHTS | 129.5" | DISTANCE FLOOR TO BED | 30.25" | WINDOW SIZE | 30" W X 15" H | CLUTCH | air clutch & brake | electrics | 30 hp 1750 rpm 480v-3-60 eddy current drive. will include new cieco 1100r6 press control for reconditioned price. | APPROX. DIMENSIONS | 13'6" h X 205" RL X 101" FB | APPROX. WEIGHT | 86,000 LBS. | Equipped With | rigid fabricated steel frame, reinforced box-type bed & slide, long gibbing & laminated nonmetallic ways, dual air counterbalances, low inertia steel gearing, twin end drive, automatic lubrication, automatic flywheel brake | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
