Machine Specifications
Straight Side Press for Sale
Manufacturer: Minster
Model: Minster E2-200-60-54 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: 1975
Machine #: 8061
Buy Now: $
| capacity | 200 ton | stroke | 8″ | max shut height to bed | 25″ sdau | bed area | 60″ X 54″ (RL X FB) | speed | 45 – 90 spm | slide adjustment | 6″ MOTORIZED | slide area | 60″ X 54″ (RL X FB) T-SLOTTED | bolster plate | 3.75″ hIGH x 60″ X 54″ (RL X FB) T-SLOTTED PLATE | distance between uprights | 60″ | distance floor to bed | 52.5″ | window size | 25″ w | clutch | minster air clutch / brake combination | electrics | 30 hp 1750 rpm 480v-3-60 motor & control | approx dimensions | 96″ X 76″ (RL X FB) X 179″ hIGH | approx weight | 71,000 lbs | Equipped With | FLOOR STANDING, TIE ROD FRAME, CAST IRON FRAME | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
