Machine Specifications
Straight Side Press for Sale
Manufacturer: Minster
Model: Minster E2-600-60-42 Press
Condition: Very Good
Location: Columbia, TN Warehouse
Year: Year Unknown
Machine #: 8056
Buy Now: $
| CAPACITY | 600 ton | STROKE | 4″ | MAX SHUT HEIGHT TO BED | 34″ sdau | BED AREA | 60″ x 42″ (rl x fb) | SPEED | 25 spm | SLIDE ADJUSTMENT | 12″ motorized | SLIDE AREA | 60″ rl x 42″ fb | BOLSTER PLATE | 6.5″ h x 60″ rl x 42″ fb | DISTANCE BETWEEN UPRIGHTS | 60″ | DISTANCE FLOOR TO BED | 36″ | WINDOW SIZE | 25″ W | CLUTCH | minster air clutch / brake combination | ELECTRICS | 50 hp 1150 rpm 480v-3-60 motor & control | APPROX DIMENSIONS | 238″ h x 109″ rl x 87″ fb | APPROX WEIGHT | 120,000 lbs | Equipped With | TIE ROD FRAME, GEARED, TWIN END DRIVE, HEAVY DUTY UPRIGHTS, EIGHT POINT GIBBING FOR PRECISION SLIDE GUIDING, HEAVY SLIDE & CONNECTIONS, DUAL AIR COUNTERBALANCES, FLOOR STANDING | Note |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
