12″ Wide x .125″ Littell Continuous Straightening Machine (5-Roll)

6

5
# of Rolls
12
Stock Width
0.230
Material Thickness

New in 1984

1
Model 412-5
12″ Wide, .125″ Rated Capacity (likely capable of .230″), 5 Roll Straightener, New in 1984, Tension Arm

Littell Flattening Machines for Sale
Used Automation Material Straightener
Machine #6217
Jackson, MI Falahee Building
Starting Price: $

Machine Specifications

Used Metal Straightener for Sale

Littell Model: 412-5
Condition: Very Good
Location: Jackson, MI Falahee Building #6217
Year: 1984
Buy Now: $





MATERIAL THICKNESS CAPACITY .125″ AT 12″ WIDE | APPROX. .230″ THICK AT 4″ WIDE
MAX. MATERIAL WIDTH 12″
NUMBER OF BREAKER ROLLS 5
PINCH ROLLS SET OF ENTRY ROLLS
PINCH ROLL SIZE APPROX. 4″ DIA.
BREAKER ROLL SIZE APPROX. 3″ DIA.
ENTRANCE / EXIT HEIGHT 48″
STANDARD SPEED APPROX. 75 FPM
ELECTRICAL 3HP 230/460V-3-60 MOTOR 1800 RPM – FR#182T
APPROX. DIMENSIONS 52″ X 65″ (RL X FB) X 78″ HIGH
APPROX. WEIGHT 1,500 LBS.
Equipped With STEEL FRAME CONSTRUCTION MANUAL LUBRICATION POINTS MANUAL PINCH ROLL TENSION ADJUSTMENT START/STOP STOCK TENSION ARM FLOOR MOUNTED BASE
Note __
Location Machine is located in Jackson, MI Falahee Building
